SICK Magnetic sensors MME

Features

• Types: M8 to M18
• Sensing range: up to 120 mm
• Electrical configuration: DC 3-wire
• Enclosure rating: IP 67
• Temperature range: –25 °C to +75 °C
• Nickel-plated brass housing; plastic sensing face
• Reliable detection of permanent magnets through non-ferromagnetic materials such as stainless steel, aluminum, plastic, or wood
• Solves high-temperature applications by installing the permanent magnet in the high-temperature area and the sensor behind an insulated area
