Havells 63 A DP Changeover

SUA00009066

Rated Frequency: 50 Hz
Ambient Temperature: -5 ⁰C to +55 ⁰C
Rated Current: 25 A, 40 A, 63 A
Rated Insulation Voltage: 690 V
Rated Impulse Voltage: 4 kV
Dielectric Strength: 2.5 kV
Standard Conformity: IS/IEC 60947-3
No. of Poles (Execution): 2-Pole, 4-Pole
Rated Voltage (Ue): 415 V
Utilization Category: AC 21 A
Electrical / Mechanical Endurance (No. of Operations): 10000
Mounting Din Rail: 35 mm x 7.5 mm
Mounting Position: Vertical/Horizontal
Terminal Capacity 25 A & 40 A: 10 mm²
Terminal Capacity 63 A: 25 mm²
