KEI 240 Sq.mm 3 Core Copper Conductor Unarmoured LT Power Cable 2XY

Rs. 0.00

Cable Length 1 Metre
Type of Product Power Cable
Model No 2XY
Conductor Material Copper Conductor
No of Core 3 Core
Voltage Rating 600/1100 V
Nominal Area 240 Sq.mm
Insulation Material PVC Insulated
Grade IS 7098 (Part 1) 1988
Title #N/A
Current Rating Direct in Ground: 421 Amp, In Air: 515 Amp
Nom. Thickness of Outer Sheath 2.8 mm
Overall Diameter 47.0 mm
Capacitance Approx. 0.31 mFd/Km
Nom. Thickness of XLPE Insulation 1.70 mm
Reactance at 50 Hz Approx. 0.072 Ohms/Km
Min. Thickness of Innersheath 0.6 mm
Armoured / Unarmoured NA
