KEI 25 Sq.mm 3.5 Core Copper Conductor Unarmoured LT Power Cable 2XY

Rs. 0.00

Cable Length 1 Metre
Type of Product Power Cable
Model No 2XY
Conductor Material Copper Conductor
No of Core 3.5 Core
Voltage Rating 600/1100 V
Nominal Area 25 Sq.mm
Insulation Material PVC Insulated
Grade IS 7098 (Part 1) 1988
Title #N/A
Current Rating Direct in Ground: 125 Amp, In Air: 122 Amp
Nom. Thickness of Outer Sheath 2.00 mm
Overall Diameter 22.4 mm
Capacitance Approx. 0.2 mFd/Km
Nom. Thickness of XLPE Insulation 0.9/0.7 mm
Reactance at 50 Hz Approx. 0.08 Ohms/Km
Min. Thickness of Innersheath 0.3 mm
Armoured / Unarmoured NA
