KEI 800 Sq.mm 1 Core Copper Conductor Unarmoured LT Power Cable 2XY

PAP00000238

Cable Length 1 Metre
Type of Product Power Cable
Model No 2XY
Conductor Material Copper Conductor
No of Core 1 Core
Voltage Rating 600/1100 V
Nominal Area 800 Sq.mm
Insulation Material PVC Insulated
Grade IS 7098 (Part 1) 1988
Title #N/A
Current Rating Direct in Ground: 758 Amp, In Air: 1148 Amp
Nom. Thickness of Outer Sheath 2.4 mm
Overall Diameter 46 mm
Capacitance Approx. 0.97 mFd/Km
Nom. Thickness of XLPE Insulation 2.60 mm
Reactance at 50 Hz Approx. 0.075 Ohms/Km
Armoured / Unarmoured NA
