KEI 95 Sq.mm 1 Core Copper Conductor Unarmoured LT Power Cable 2XY

PAP00000209

SKU EL.CA.LT.KE4.273502
Cable Length 1 Metre
Type of Product Power Cable
Model No 2XY
Conductor Material Copper Conductor
No of Core 1 Core
Voltage Rating 600/1100 V
Nominal Area 95 Sq.mm
Insulation Material PVC Insulated
Grade IS 7098 (Part 1) 1988
Title #N/A
Current Rating Direct in Ground: 264 Amp, In Air: 307 Amp
Nom. Thickness of Outer Sheath 1.8 mm
Overall Diameter 17.6 mm
Capacitance Approx. 0.79 mFd/Km
Nom. Thickness of XLPE Insulation 1.10 mm
Reactance at 50 Hz Approx. 0.085 Ohms/Km
Armoured / Unarmoured NA
