SICK Accessories: Further accessories MBR-030-KLB

SAS00004094

Accessory group Magnets
Description Magnetic tape ring: inner diameter 30 mm, outer diameter 44 mm, width 10 mm, weight ≤ 0.25 kg, magnetic tape material: 17410 hard ferrite 9/28 P, material ring: Aluminum, period length: 2 mm, operating temperature range: –30 °C ... 100 °C, storage temperature range: –30 °C ... 100 °C, temperature coefficient: (11 ± 1) μm/K/m
Material 17410 Hard ferrite 9/28 P
Temperature resistance min ... max –30 °C ... +100 °C
Inner diameter 30 mm
Outer diameter 44 mm
Width 10 mm
Weight ≤ 0.25 kg
Period length 2 mm
Operating temperature range –30 °C ... +100 °C
Storage temperature range –30 °C ... +100 °C
Temperature coefficient (11 ± 1) μm/K/m
