HENSEL RX 0207 T | Cable Junction Boxes IP 66

RX 0207 T

• 0.5-4 mm², Cu
• 7 terminal blocks WKM 2.5/15
• Per terminal 2 x 0,5-2,5 mm² f or 2 x 0,5-4 mm² sol,
  see Technical details for more information about terminal assignment
• Nominal current of the terminal depending on conductor cross section. See instruction manual or www.hensel-electric.de > Products
• Terminal blocks, by Wieland
• Terminal marking, neutral
• For hazardous areas, can be used in Zone 2 and Zone 22
• Cable entries can be drilled individually, order AXM separately (see cable entry systems LES)
• Permitted size of the cable entry system: M20
• "Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
• External brackets for wall fixing included
• Colour: black, RAL 9011
